HVACDIRECT Tech HVAC Kit (Vacuum Pump, Refrigerant Manifold & Digital Vac Gauge)

HVACDIRECT Tech HVAC Kit (Vacuum Pump, Refrigerant Manifold & Digital Vac Gauge)

KIT12

This HVACDIRECT KIT12, Tech HVAC Kit (Vacuum Pump, Refrigerant Manifold & Digital Vac Gauge) is a high quality tool kit that is ideal for basic HVAC requirements. Included in this kit are some of HVAC Direct's best selling products.

Kit contains:

#1. JAVAC CAL Series, 45 L/min, 2-stage Vacuum Pump - R32 Compliant

VCL452

This JAVAC CAL Series VCL452 is a quality 2-stage, oil rotary vane pump with a 45 L/min flow rate and a 15 micron ultimate vacuum.

This pump is ideal for general refrigeration service, and is packed with the features below.

Applications:

• Bottle shops, convenient stores, restaurants and catering facilities

• General Refrigeration

• Residential or Industrial

• Split system installation or servicing

Features/Benefits:

• Comes with a free starter bottle of oil
• R32 and 1234yf compliant
• Manufactured to JAVAC's high quality standards
• 45 L/min flow rate
• 15 micron ultimate vacuum
• Ballast valve
• Anti-oil demister to prevent oil spillage
• Fitted with a tri-connector: 1/4", 3/8" & 5/16" SAE
• 350ml oil capacity
• Dimensions (mm): 330x135x255
• Weight (kg): 9.6kg

#2. JAVAC 2-Valve Refrigeration Manifold Set - R32 & R410a Compliant

JAVA66336

This JAVAC JAVA66336, 2-Valve Refrigeration Manifold Set has evolved from over 50 years of industry knowledge. With a 36" hose set and large 80mm gauges, this manifold set is designed for consistently accurate professional use.

Features:

• High quality aluminium body
• Piston values
• Soft ergonomic with colour-coded knobs
• Heavy-duty swivel hanging hook
• Heavy-duty black carry case
• 80mm gauges with soft cushion-protective cover, pulse-free pointer, zero-pointed calibration and colour-coded

Specifications:

• 800 psi max recommended working pressure
• Burst pressure 4,000 psi
• Red, blue & yellow hoses: 72", 5/16" SAE connections
• Included: 2-Valve Refrigeration Manifold, 3-piece hose set, hanging manifold hook & carry case

#3. HVD - Digital Vacuum Gauge

JAVG1

This HVD G1 Digital Vacuum Gauge obtains highly accurate vacuum measurements prior to filling refrigerants. It features a vacuum sensor to precisely measure vacuum in refrigeration and A/C systems, along with a wide range of other industrial fields. Leading IP65 water resistance for field technicians offers additional peace of mind.

Features:

• 0-75000 micron range
• Overload pressure - 14PSI/0.1MPA
• Measures: Torr(mmHg), mbar, Pa, Micron

• Auto-off - 10 minutes
• Sensor - Pirani
• High/low pressure alarms
• LCD display with backlight

• Carry bag

Specifications:

• Measuring range: 0-75000 micron

• Operating temperature: 0°C - 50 °C

• Ranges

• 0-10000 Pa
• 0-100.00 mBar
• 0-75.000 Torr
• 0-75000 Microns

• Fitting: 1/4″ M SAE

• Accuracy: +/– 10%

• Product size (mm): 127x74x37

• Power supply: x3 AA batteries

• Max overpressure: 14PSI,0.1Mpa

• Battery life: 200 h

• Units: Torr(mmHg), mbar, Pa, Micron
